XPEDITION PLUS 16FT POP-TOP CARAVAN

Go further, stay longer, live bigger. An off-grid hybrid caravan for couples and families who want to travel remote without giving up comfort.

The Xpedition Plus

The Xpedition Plus is our 16ft off-road hybrid caravan for couples and families who want to travel remotely without giving up comfort. Based on the Xpedition MKII, we lengthened the body for a larger ensuite and a full-width sitting area that folds down into a second double bed.

Like every hybrid in our range, you will see it called a hybrid camper, a hybrid camper trailer or a hybrid caravan. It is one off-road, off-grid rig under three names. If you are shopping for a hybrid caravan for sale that shrugs off corrugations and weeks off the grid, the Xpedition Plus is the one to compare.

Technical Specifications

TYPE

Hybrid Caravan

TARE

2480kg

ATM

3000kg

LENGTH

6.8m

WIDTH

2.15m

HEIGHT

2.55m

BALL WEIGHT

220kg

Download the brochure

Download the accessories list

Inclusions

608ah Lithium Batteries – Option for up to 912ah
600W Roof Mounted Mono Crystaline Solar Panels
Redarc Manager Alpha 50 BMS with Redvision Display
Redarc or Enerdrive 2000W Pure Sine Wave Invertor with Pass through to 240V system
Truma Ultra Rapid Hot Water 14 litre storage unit, Operates on Gas & 240v
Dometic Fresh Jet Ultra Lite 2.6kw Invertor Airconditioner – Roof Mounted
24″ Engalon Smart TV with built in Chromecast and BT Connection
Premium Sound system with speakers inside and out with Bluetooth Connection
12V 3speed Gimbal Fan 360 degree range x 2
Anderson plug connectors for vehicle and solar input for extra panels
Electric Emergency Breakway with 2 ADR Compliant Safety Chains
Multiple 12v & USB sockets, inside and out
Internal and External LED Lights with Orange Insect Repellant option
50lt internal Fridge
700w 240V Microwavve
Wireless Camera with 7″ Screen, wired to driving and reverse lights

Multiple storage Compartments inside & out
Fridge Slide: 980mm long x 550mm wide x 480mm high
Provision for Rear bike rack tongue / receiver
1 x 8.5kg and 1 x 3.75 kg gas bottle holders stored in weatherproof compartment

Sleeping accomodation for 4
Pocket Spring Mattress with Memory Foam Topper Size 150cm wide x 195cm long x 20cm Thick.
Caffe Lounge converts to Double Size Bed 2000mm long x 1200mm wide
Reading lights either side of bed with 12v socket & USB Connection, Fans

Fully Enclosed Annex with Roof, Walls, Side Skirt,PVC Floor
Windows Tinted, Inside Flyscreen and Blockout Blinds
Self repairing zippers to all Annex windows & doors
4.5M Awnlux Cassette Electric awning with anti flap kit included
Aussie Traveller Split Dual entry door with flyscreen mesh and roller Blind fitted
Large Ensuite with Thetford Toilet, Shower and other ammenities
External Shower Ensuite with Mixer Tap
Sleeping accomodation for 2 or 4
Pocket Spring Mattress with Memory Foam Topper Size 150cm wide x 190cm long x 20cm Thick
Bench Style seating with long adjustable Table, Main bed converts to extra lounge area
Reading lights either side of bed with 12v socket & USB Connection, Fans

Heavy Duty Coil Springs paired with Adjustable Independent Suspension
***OPTIONAL CRUISEMASTER ATX COIL OR AIRBAG SUSPENSION***
Lovells Gas Shock Absorbers Heavy Duty 16mm Eye
Diesel Heater 2kw Plumbed with 15l tank
External Kitchen with Thetford Combination 3 Burner Stove and sink, bench Extension & Gas Compliance
Internal Kitchen with Dometic 2 Burner Stove and Sink
External Kitchen fully plumbed water and electrics, no manual connections required
Fold down pantry with multiple storage areas
4 ‘drop down’ adjustable stabiliser legs – Optional ARK Jack Legs available
Cruisemaster DO35 Hitch 3.5T and trailer plug included to suit your tow vehicle
Swing down Aluminium Entry step
Rock Sliders each side to protect underbody
Dual rear rated 4.5T Heavy Duty recovery shackles
265/75 R16 MT or AT Tyres on Alloy Rims, Rear mounted spare Tyre with Toolbox (second spare opt)
200ltr Total Fresh Water capacity (F-80ltr & R-120ltr) + 80lt Grey Water Tank – Poly Food Grade Tanks
John Guest water hoses and Fittings, Watermarked Food Grade safe.
Drawbar Mounted Water tap
Seaflo 9.5lm Water Pump with John Guest Hose and Fittings
Seaflo Mains water connection with Pressure Reducing Valve
Fully Welded Aluminium Body, Underbody Sealer, Proof Coated with Mud Flaps
Drawbar Full Length RHS Galvanised 150x50x4mm
RHS Galvanised Chassis 100x50x4mm Proof Coated
12” Electric Brakes with Mechanical Handbrake and Electric breakaway
ARK XO 750kg rated Off Road Dual Wheel Jockey Wheel
***LIFETIME CHASSIS AND DRAWBAR WARRANTY***

Features

A fully welded aluminium body sits on a chassis and drawbar covered by a lifetime warranty, so the Xpedition Plus holds up to rough terrain and years of touring.

Inside, the lengthened body makes room for a larger ensuite with a Thetford toilet and shower, and Dometic air conditioning keeps the van comfortable in summer heat and cold desert nights. The full-width sitting area converts to a second double bed, so the same space works for a couple who want room to relax or a family who need the extra berths. Two kitchen zones, one internal and one external, are fully plumbed and ready to use, with a Thetford 3-burner stove inside and a Dometic 2-burner outside for cooking in the open.

The living space carries modern touches: a 24" smart TV, a Bluetooth sound system, and multiple USB and 12V outlets for charging. Orange insect-repelling lights run inside and out, so you can leave the door open at dusk without the bugs following you in.

For serious travel, the Xpedition Plus runs adjustable suspension and rock sliders to clear obstacles and protect the body off-road. An electric awning, dual gas bottles, ample storage and provisions for bike racks mean you can load up everything a long trip needs and still have somewhere to put it.

Videos

Video Playlist

1/1 videos

Xpedition Plus – Built for the Long Haul, Ready for the Wild!

XPEDITION PLUS 16FT POP-TOP CARAVAN FAQs

Is the Xpedition Plus a hybrid camper or a hybrid caravan?
Both terms describe it. The Xpedition Plus is a 16ft off-road hybrid, sold as a hybrid caravan and often searched as a hybrid camper or hybrid camper trailer. It is one off-grid rig under three names.

How many people does the Xpedition Plus sleep?
The Xpedition Plus sleeps 2 or 4. A full-width sitting area folds down into a second double bed, so couples get extra living space and families get the extra berths when they need them.

What does the Xpedition Plus weigh, and can I tow it?
The Xpedition Plus has a Tare of 2,480kg and an ATM of 3,000kg, with a 220kg ball weight. Check your vehicle’s towing capacity and towball rating against these figures, since the loaded weight sits up to 3,000kg.

How long can the Xpedition Plus run off grid?
A 608Ah lithium system, upgradable to 912Ah, pairs with 600W of solar and a 2,000W inverter to run the fridge and appliances for days off grid. A 200L fresh water tank lets you stay out longer between refills.

What is the water capacity of the Xpedition Plus?
The Xpedition Plus carries 200L of fresh water, enough for a couple to camp off grid for several days before a refill. Dual kitchens, one internal and one external, are plumbed and ready to use.

Where can I see an Xpedition Plus?
You can view the Xpedition Plus at the Bluewater yard, 19 Gillam Drive, Kelmscott, WA. Request a quote online or book a viewing to walk through one before you buy.

Ready to go further and stay longer?

Request a quote on the XPEDITION PLUS 16FT POP-TOP CARAVAN, or come and walk through one at our Kelmscott yard.
